JALTEST MARINE INBOARD USA - ONE YEAR LICENSE OF USE

Jaltest Marine Inboard USA — One Year License of Use

The Jaltest Marine Inboard USA — One Year License of Use (Part #74601003) activates inboard marine engine diagnostics within the Jaltest platform for a full year. This is the targeted license for marine service shops, boat dealers, and marina tech departments whose work centers on inboard-powered vessels — cabin cruisers, sport boats, and other craft running inboard engines such as Volvo Penta IPS, Volvo Penta KAD/KAMD/TAMD, and MAN marine powerplants.

If your shop does not service outboard motors or personal watercraft, the Inboard license gives you exactly the coverage you need without paying for modules you will not use. It operates within the same Jaltest interface as your other diagnostic modules and requires an active Jaltest Link V9 hardware unit.

What the Jaltest Marine Inboard License Covers

• Volvo Penta IPS and Sterndrive: Full ECU access on Volvo Penta inboard and IPS-drive systems via JDC527A (6-pin) and JDC528A (8-pin) cables
• Volvo Penta KAD / KAMD / TAMD Series: Legacy and current Volvo Penta diesel inboard platforms via JDC618A9 (A9 diagnostics cable)
• Volvo Penta EGCI / OBD-M: Covered via JDC611A (OBD-M diagnostics cable / Volvo Penta EGCI 6-pin)
• Mercury / Mercruiser Inboard: Mercury 4-pin (JDC603A), Mercury 10-pin (JDC604.9), Mercury 2-pin (JDC614A9), DTS Mercury/Mercruiser (JDC617A)
• Yanmar Marine: Yanmar 3-pin inboard diagnostics via JDC612A cable
• MAN Marine: MAN marine diesel inboard systems via JDC620A cable
• Fault Code Reading and Clearing: Full DTC access with OEM-level code definitions across all supported inboard ECUs
• Live Data Monitoring: Real-time engine parameters — RPM, coolant temp, oil pressure, fuel delivery, and control module outputs
• Actuator and Component Tests: Where supported by OEM platform, run actuator tests and component-level diagnostics
• System Calibrations: Calibration functions for supported systems

Recommended Inboard Cable Kit

Pair this license with the Inboard Cable Kit (Part #70002009, MSRP $580), which includes: JDC527A (Volvo Penta 6-pin), JDC603A (Mercury 4-pin), JDC604.9 (Mercury 10-pin), JDC611A (OBD-M/Volvo Penta EGCI), JDC612A (Yanmar 3-pin), JDC614A9 (Mercury 2-pin), JDC617A (DTS Mercury/Mercruiser), JDC618A9 (Volvo Penta KAD/KAMD/TAMD A9). This kit covers the major inboard engine brands you will see in any well-rounded marine service bay.

License Terms and Requirements

• One-year license from date of activation
• Added licenses align with the main Jaltest license expiration date; cannot exceed one year from activation
• Maximum 3 PC installations per license
• Active Jaltest Link V9 hardware required to run software
• Windows 10 or newer; minimum 20GB storage, 2GB RAM, Intel Gen 3+ processor, Bluetooth
• Internet connection required for troubleshooting, vehicle technical data, and releases/procedures modules

Inboard vs. Full Marine License

The Inboard license is priced below the Full Marine and Boat licenses because it covers one specific vessel category. If your shop exclusively handles inboard-powered vessels, this is the right license. If you also work on outboard motors, you would add the Outboard license (74601004) separately, or step up to the Full Marine license (74601001) which covers all four categories at a lower combined cost than buying each module individually.

Hardware Required

The Jaltest Marine Hardware Kit (Part #70001023, MSRP $1,490) provides the Jaltest Link V9 interface, USB cable, OBD cable, Multipin kit, 2.5m extension cable, and transport hardcase — everything needed to run marine diagnostics except the marine-specific connector cables.
