JALTEST MARINE FULL USA- ONE YEAR LICENSE OF USE

Jaltest Marine Full USA — One Year License of Use

The Jaltest Marine Full USA — One Year License of Use (Part #74601001) is the most comprehensive marine diagnostic software license available for Jaltest users in the United States. It unlocks the complete Jaltest Marine module, covering all four marine vessel categories in a single license: inboard engines, outboard engines, boat (combined inboard/outboard vessel diagnostics), and personal watercraft (jet ski). If your marina, boat dealership, or marine service shop works across multiple vessel types and engine configurations, this is the license that covers everything without juggling separate module purchases.

This is an add-on license that extends your existing Jaltest diagnostic hardware kit. You need an active Jaltest kit (Jaltest Link V9 hardware) before activating this license. The one-year term begins at activation and cannot exceed your main license expiration date if added mid-cycle.

What the Jaltest Marine Full License Covers

• Inboard Engines: Full ECU diagnostics on marine inboard powerplants — fault code reading and clearing, live data monitoring, actuator tests, and system calibrations on supported brands
• Outboard Engines: Multi-brand outboard motor diagnostics including Yamaha, Mercury, Honda, Kawasaki, Suzuki, Evinrude, BRP Seadoo motor systems, and more
• Boat (Combined Vessel): Full coverage for vessels running both inboard and outboard configurations, plus complete boat system diagnostics
• Personal Watercraft / Jet Ski: Diagnostics for jet ski and personal watercraft platforms including BRP Seadoo and Kawasaki jet ski systems
• Volvo Penta: Supported via dedicated cables (JDC527A 6-pin, JDC528A 8-pin, JDC618A9 KAD/KAMD/TAMD A9)
• Mercury / Mercruiser: Supported via JDC603A (4-pin), JDC604.9 (10-pin), JDC614A9 (2-pin), JDC617A (DTS)
• Yamaha: Supported via JDC601A cable
• Honda Marine: Supported via JDC608A cable
• Suzuki Marine: Supported via JDC613A (8-pin) and JDC616A (4-pin) cables
• Evinrude / BRP: Supported via JDC609.9 (Evinrude), JDC602A (BRP Seadoo), JDC628A (Evinrude NMEA 2000)
• Kawasaki: Supported via JDC610A (4-pin) cable
• Yanmar Marine: Supported via JDC612A (3-pin) cable
• MAN Marine: Supported via JDC620A cable

Diagnostic Capabilities

• Read and clear DTCs across all supported marine ECUs
• Live data streaming for engine parameters, sensor readings, and system status
• Actuator and component tests
• System calibrations where supported by the OEM platform
• Multi-system access: engine management, fuel systems, and electronic controls

Required Hardware

This license requires the Jaltest Marine Hardware Kit (Part #70001023, MSRP $1,490), which includes the Jaltest Link V9, USB cable, OBD diagnostics cable, Multipin kit, 2.5m SUBD-26 extension cable, and transport hardcase. Marine-specific cables are sold separately — Cojali USA offers pre-configured cable kits for each vessel category (Boat, Inboard, Outboard, Jet Ski) to simplify ordering.

License Terms

• One-year license from date of activation
• If added to an existing Jaltest kit mid-cycle, license aligns with the main license expiration date but cannot exceed one year from activation
• Up to 3 PC installations per license
• Active Jaltest hardware (Jaltest Link V9) required to run the software
• Internet connection required for troubleshooting by fault code, vehicle technical data, and releases/procedures modules

Who Needs the Marine Full License?

The Full license makes sense for marine service operations that work across multiple vessel types — a dealership or independent marine shop handling both outboard-powered fishing boats and inboard-powered ski boats, plus personal watercraft service. Buying the Full license eliminates the need to purchase and manage separate Inboard, Outboard, and Watercraft licenses. If your shop is exclusively inboard or exclusively outboard, the targeted single-category licenses (74601003 Inboard, 74601004 Outboard) offer a lower entry point. But if you do it all, the Full license at $1,000/year is the practical choice.
