JALTEST MARINE BOAT USA - ONE YEAR LICENSE OF USE

Jaltest Marine Boat USA — One Year License of Use

The Jaltest Marine Boat USA — One Year License of Use is the Jaltest Marine module specifically designed for boat diagnostics — covering vessels that run inboard/outboard combined configurations as well as complete boat-system diagnostics. This license activates within your existing Jaltest diagnostic platform and gives your marine shop access to multi-brand boat engine and system diagnostics through the same Jaltest interface you already use for other equipment categories.

This is an add-on license that extends an existing Jaltest kit (Jaltest Link V9 hardware required). The Boat module is positioned between the single-category Inboard and Outboard licenses and the Full marine bundle — it is suited to shops whose primary work is on conventional powerboats as opposed to dedicated outboard-only or personal watercraft specialty operations.

What the Jaltest Marine Boat License Covers

• Inboard Marine Engines: ECU diagnostics for inboard powerplants including Volvo Penta (KAD/KAMD/TAMD series via JDC618A9, 6-pin via JDC527A, 8-pin via JDC528A)
• Outboard Engines on Boats: Yamaha outboards (JDC601A), Mercury (JDC603A 4-pin, JDC604.9 10-pin, JDC614A9 2-pin, JDC617A DTS Mercruiser), Honda (JDC608A), Kawasaki (JDC610A), Suzuki (JDC613A 8-pin, JDC616A 4-pin), Evinrude (JDC609.9)
• OBD-M / Volvo Penta EGCI: JDC611A cable supports OBD-M diagnostics and Volvo Penta EGCI 6-pin systems
• Yanmar Marine (3-pin): Supported via JDC612A
• Fault Code Diagnostics: Read and clear DTCs across all supported boat engine ECUs with manufacturer-specific code definitions
• Live Data: Real-time parameter monitoring for engine speed, temperature, fuel systems, and electronic control modules
• Actuator Tests: Component-level testing where supported by the OEM platform

Recommended Cable Kit for Boat Diagnostics

Cojali USA offers the Boat Cable Kit (Part #70002008, MSRP $880) which includes the following cables designed for boat diagnostics: JDC527A (Volvo Penta 6-pin), JDC601A (Yamaha), JDC603A (Mercury 4-pin), JDC604.9 (Mercury 10-pin), JDC608A (Honda), JDC609.9 (Evinrude), JDC611A (OBD-M/Volvo Penta EGCI), JDC612A (Yanmar 3-pin), JDC613A (Suzuki 8-pin), JDC614A9 (Mercury 2-pin), JDC616A (Suzuki 4-pin), JDC617A (DTS Mercury/Mercruiser), JDC618A9 (Volvo Penta KAD/KAMD/TAMD). The cable kit covers the full range of engines you will encounter on typical powerboats.

License Terms

• One-year license from date of activation
• If added mid-cycle to an existing Jaltest kit, aligns with the main license expiration but cannot exceed one year from activation
• Up to 3 PC installations per license
• Active Jaltest Link V9 hardware required to execute software
• Internet connection required for troubleshooting by fault/symptom, vehicle technical data, and releases modules

Boat vs. Full Marine License — Which Do You Need?

The Boat license covers powerboat diagnostics across inboard and outboard engine platforms. If your shop also services personal watercraft (jet skis), you would either add the Watercraft license separately (74601005) or step up to the Full Marine license (74601001) which bundles all four categories. For shops doing exclusively powerboat work with no jet ski service, the Boat license is the right size.

Hardware Requirement

The Jaltest Marine Hardware Kit (Part #70001023, MSRP $1,490) is required. It includes the Jaltest Link V9 interface, USB cable, OBD cable, Multipin kit, 2.5m extension cable, and transport hardcase. License activates on top of this hardware platform.
